Characteristic：
1. 3 inch and 6 inch shaftless air Pressure cone top unwinding
2.Laser paper core positioning technology
3.Error correction method EPC/LPC (web guide)
4.Main control system (PLC+ HMI)
5.Subsection tension control technology(auto tape control)
6.Drive mode (Asynchronous servo motor control)
7.Cutting methods (straight cut or round cut)
Main Technical Variables：
| Mechanical speed |
400m/min |
| Max. unwinding diameter |
1000mm |
| Max. rewinding diameter |
800mm |
| Cutting width |
50-1300mm |
| Driving type |
3 Motor |
| Cutting type |
Round cutting knife (上刀105mm,下刀90mm) |
| Main control system |
PLC+Interface) |
| Web guide type |
EPC |
| Machine weight |
5000kg |
| Overall dimensions(L x W x H) |
3500 x 3100 x 1950mm |
|
